Winpact Chiller, WCC-201
WCC-201 provide precise temperature control and excellent cooling performance for your fermentation needs and beyond
製品説明
The Winpact Chiller series is major science’s newest addition to the bioprocessing technology portfolio to provide precise temperature control and excellent cooling performance for your fermentation needs and beyond. The recirculating chillers are compactly designed and require very little space; the built-on wheels offer an added bonus of mobility to any space-conscious labs. With a low procurement cost, it is your best option to stray away from costly tap water and is the perfect alternative for basic cooling needs..
- Temperature Control Range (No-load) -10°C~100°C
- Cooling Capacity Maximum is 1800W(1.8kW)
- Refrigerant Filling weight 220g
- Tank Volume 20L
* All images are for reference only, actual products might differ from the pictures above.
* Technical specifications subject to change without notice.
| Cat. No. | WCC-201 |
|---|---|
| Temperature Control Range (No-load) |
-10°C~100°C |
| Cooling Capacity | Maximum is 1800W(1.8kW) |
| Temperature display resolution | 0.01°C |
| Temperature Stability | ±0.05°C |
| External Circulation Flow Rate | 13L/min |
| Pump Head (Max.) | Maximum Head: 3 m |
| Pump Pressure (Max.) | approx. 0.29 bar |
| Refrigerant Type | 404A or134A |
| Refrigerant Filling weight | 220g |
| Tank Volume | 20L |
| Tank Material | SUS304 |
| Tank Depth(mm) | 280 |
| Tank Opening Size(mm) | 235x160 |
| Overall Dimensions(mm) | L380xW410xH990 |
| Input Power | 220VAC, 50/60Hz |
| Rated Power | 2500W(2.5kW) |
| Working Medium | Pure Water or Anhydrous Ethanol |
| IP Code | IP43 |
| Sound pressure level dbA | 20 |
| External Circulation Port Size | G1/2 male thread with optional barbed connectors for 8, 10, 12 mm outer diameter hose |
| Net Weight | Approx. 45kg |
| Cat. No. | Product Description |
|---|---|
| WCC-201 | Winpact Chiller, 110V |
